High Temperature White Micalex Macor Ceramic Components Machinable Block Macor Insulator

technical white micalex macor ceramic components custom

Product Description

Macor mica machinable Ceramics:

Microcrystalline glass ceramics have excellent processing properties, vacuum properties, electrical insulation properties, and high temperature and chemical resistance. Glass-ceramics with high mechanical strength, glass-ceramics, machinable glass-ceramics and bioactive glass-ceramics

Macor ceramics have excellent processing properties, vacuum properties, electrical insulation properties, and high temperature and chemical resistance. Glass-ceramics with high mechanical strength of glass-ceramics, machinable glass-ceramics and bioactive glass-ceramics.

High Temperature White Micalex Macor Ceramic Components Machinable Block Macor Insulator

Data sheet

Machinable mica (Macor) Ceramic Properties
Item	Unit	Typical Values
Physical Properties
Color		White
Main Composition		Mg3K[AlF2O(SiO3)3],SiO2
Density	g/cm3	2.60
Apparent Porosity		0.07%
Water Absorption		0
Normal Temperature Outlet Rate	ml/S·cm2	8.8*10-9
Helium Transmission Rate	ml/S	1*10-10
Mechanical Properties
Rockwell Hardness(45N)	R45N	40
Vickers Hardness (Load 500g)	Gpa(Kg/mm2)	11.5(1175)
Flexural Strength (20°C)	Mpa	>108
Compressive Strength (20°C)	Mpa	>508
Modulus of Elasticity (25°C)	Gpa	65
Impact Toughness	KJ/m2	>2.56
Thermal Properties
Thermal Conductivity (25°C)	W/m.K	1.71
Thermal Expansion Coefficient	10-7/°C	72
Thermal Shock Resistance	T°C	200
Perennial Temperature	°C	800
Electric Properties
Dielectric Strength	KV/mm	>40
Volume Resistivity(25°C)	Ω.cm	1.08*1016
Volume Resistivity(200°C)	Ω.cm	1.5*1012
Volume Resistivity(500°C)	Ω.cm	1.1*109
Dielectric Loss		1-4*10-3
Dielectric Constant	Er	6-7

Application industry:

Machinery, electronic, limitary, aerospace etc.

Specific application: Machined equipment high temperature insulated parts, electronic equipment high temperature insulated parts.

Macor ceramics are particularly suitable for automotive, military, aerospace, precision instruments, medical equipment, electric vacuum devices, electron beam exposure machines, textile machinery, sensors, mass spectrometers and energy spectrometers. For some thin-walled coil bobbins, precision instrumented insulation brackets, and complex-shaped devices with high precision requirements, glass-ceramics are more suitable, and they can be processed into any shape.

Company Introduce

Wuxi Special Ceramic Electrical Co.,Ltd mainly produces alumina, Silicon nitride, Zirconia, Steatite, Boron nitride, Cordierite,mullite products, widely used in metal welding, electronic conductor, mechanics, assembling, insulation, chemicals, instrument, textile, nuclear industry, aerial field.We accept trial produce according to the drawing or sample.It usually takes 15 days to finish trial product.Mass produce usually takes 30 days.Goods' package is carton or PLT.It can be negotiable with each other.
We mainly sell goods to toshiba lighting group in Japan and Europe.Our aim is to deliver goods with high quality at quick delivery date.

Quality Control

mass production by 100% inspection
